Mitsubishi windscreen replacement

What Mitsubishi windscreen features mean

Tap a feature to see what it is, how to spot it on your car, and how it affects glass replacement. We confirm the exact match for your vehicle when you book.

• Green114

  1983–2026

  Green tint reduces glare and improves visual comfort by filtering certain light wavelengths.

  What it means

  Green tint is a light-filtering coating applied to the glass during manufacture. It absorbs and reduces transmission of certain wavelengths of light, primarily to cut glare from sunlight and reflections. The tint is subtle — often barely visible to the naked eye — but measurably improves visual comfort during prolonged driving, particularly in bright conditions. It's a factory specification chosen by the vehicle manufacturer to balance daylight comfort with interior visibility and aesthetic consistency across all glass in the vehicle.

  How to tell

  The easiest way to check is to roll your side window halfway down and hold a piece of white paper behind it. Look carefully for a tint cast — green tint will appear as a subtle green hue compared to clear glass. Your windscreen will have the same tint as your side windows. You can also ask your vehicle's dealership or service centre — they'll have the original specification on file.

  Replacement impact

  Green-tinted replacement glass must match the original tint specification to maintain visual consistency across all windows and preserve the vehicle's interior aesthetics. Aftermarket OE-equivalent (OEE) green-tinted glass is widely available, though some vehicles may require original equipment (OEM) dealership glass if the tint specification is proprietary. Tint does not affect calibration, cure time, or installation procedure — it's a cosmetic and functional specification only.

• Rain Sensor42

  2000–2026No calibration after replacement

  Your wipers automatically activate when rain falls on the windscreen.

  What it means

  A rain sensor is a device mounted on or behind the windscreen that detects moisture and triggers the wiper system automatically. The sensor uses infrared light to measure water droplets on the glass surface and signals the vehicle's electrical system to engage the wipers without driver input. This feature improves safety in sudden downpours and reduces driver workload in variable weather conditions.

  How to tell

  Check your windscreen for a small sensor unit, usually mounted near the top centre behind the glass or at the base of the mirror. Look for a small dark component or lens. If your vehicle has automatic wipers that activate without you toggling the stalk, you have a rain sensor. Ask your dealer or service centre to confirm; they can check your vehicle records or wiper module settings.

  Replacement impact

  Rain sensors are non-structural elements and do not require recalibration after windscreen replacement. The sensor bracket or mounting may need careful removal and reinstallation to ensure it sits correctly behind the new glass. If the sensor itself is damaged during removal, a replacement unit may be needed. Your fitter will confirm the condition and refit or replace the sensor as part of the standard replacement procedure.

• Blue Sun Strip27

  1983–2026

  A blue-tinted gradient band across the top of your windscreen that reduces glare without affecting your view of the road.

  What it means

  A blue sun strip is a tinted gradient band built into the upper edge of your windscreen's laminate layer. It reduces glare from sunlight reflecting off the road and bonnet without darkening your main field of vision. The tint is created during manufacture as part of the glass laminate itself — it cannot be added or removed later. Sun strips are a windscreen-only feature; rear and side windows cannot carry this effect because they use tempered rather than laminated glass.

  How to tell

  Look at the top of your windscreen from inside the car — you'll see a distinct blue-tinted band running horizontally across the upper portion. Check your vehicle's specification sheet or ask your dealership service centre whether your windscreen is listed as a 'blue sun strip' or 'tinted sun strip' variant. Your invoice or parts manual will confirm it.

  Replacement impact

  When replacing a windscreen with a blue sun strip, the replacement must be the sun-strip variant — a standard plain windscreen will not replicate the tinted band. Your replacement glass is sourced as an exact match to your original specification. There are no additional calibration or cure implications beyond a standard windscreen replacement. Fitting and drive-away times remain unchanged.

• Vin Notch27

  2008–2026

  A printed VIN reference box along the bottom edge of your windscreen helps identify your vehicle's chassis number at a glance.

  What it means

  A VIN (Vehicle Identification Number) notch is a small printed or etched box positioned along the lower edge of the windscreen that displays your vehicle's chassis number. This reference marking is a manufacturing and administrative feature, allowing quick visual identification of the vehicle without needing to consult documents. It's particularly useful for service records, insurance claims, and vehicle registration purposes. The notch itself doesn't affect the structural integrity or safety performance of the glass.

  How to tell

  Look along the bottom edge of your windscreen — typically in one of the lower corners — for a small rectangular box containing printed digits or characters. If you're uncertain, check your vehicle's service handbook or ask your dealership or service centre to confirm whether your model includes this feature.

  Replacement impact

  When your windscreen is replaced, the new glass will retain the VIN notch printed or etched by the manufacturer. This is a standard feature on replacement windscreens for compatible vehicles and requires no additional work or adjustment. The notch does not affect glass fitting, cure time, or any post-replacement calibration procedures.

• Blue25

  1978–2026

  Blue-tinted windscreens reduce glare and heat while maintaining a subtle, modern appearance.

  What it means

  A blue tint is a light coloration applied to the windscreen glass, usually during manufacture. It reduces solar heat transmission and glare from sunlight, particularly on bright days or when driving into the sun. The tint is integral to the glass itself — not a separate film — and is chosen by the vehicle manufacturer to balance comfort, visibility, and aesthetic consistency with the vehicle's side windows and rear window. Most vehicles come with a green or blue tint as standard; the choice depends on the manufacturer's design and regional climate considerations.

  How to tell

  Check your side windows by rolling one halfway down and holding a white piece of paper behind the glass. If you see a blue tint reflected in the glass, your windscreen will have the same tint. You can also ask your vehicle's dealership or service centre to confirm the windscreen tint specification. The tint is visible when comparing the windscreen to clear glass, though it may be subtle and harder to spot on overcast days.

  Replacement impact

  Blue-tinted replacement windscreens must match the original tint to maintain visual consistency with your side and rear windows. Most replacement glass is available in the correct tint through OE (original equipment) suppliers. There is no calibration requirement related to tint. The tint does not affect fitting time, cure time, or drive-away schedules. Ensure the replacement windscreen is specified with the blue tint to avoid a mismatched appearance.

• Acoustic (Noise reduction)21

  2000–2026

  Acoustic glass reduces cabin noise for a quieter, more comfortable ride.

  What it means

  Acoustic windscreen glass is laminated with a special acoustic interlayer that absorbs and dampens sound vibrations. It reduces exterior noise—from traffic, wind, and road surface—before it enters the passenger compartment. This makes the cabin noticeably quieter and creates a more peaceful driving experience. It's a comfort feature, not a safety one; standard laminated windscreens already meet impact safety requirements.

  How to tell

  Check your windscreen for an ear symbol, the word 'Acoustic', a capital 'A', or the term 'SoundScreen' printed in one of the four corners. These markings indicate acoustic-grade glass. You can also ask your vehicle's dealership or service centre whether your model came fitted with acoustic glass—it's often a factory option on comfort or premium trims.

  Replacement impact

  Acoustic glass is always laminated and bonds to the frame like any standard windscreen, so replacement follows the normal bonded-glass procedure. No specialist calibration is required. The replacement technician will fit it using standard adhesive and sealant. Cure time and drive-away restrictions are identical to standard laminated windscreens. Acoustic glass is widely available as an aftermarket OE-equivalent option.

• Heated Windscreen21

  1991–2026

  Heated windscreens use embedded wires to quickly clear ice and condensation in cold weather.

  What it means

  A heated windscreen is integrated with a fine mesh of electrical wires embedded within the glass itself. When activated, these wires generate heat to warm the windscreen surface, helping to rapidly clear frost, ice, and condensation during cold or damp conditions. This feature improves visibility and safety in winter driving and reduces reliance on engine heat and demister air, which can be slower on very cold mornings.

  How to tell

  Check your vehicle's handbook or contact your dealership service centre — they can confirm whether your model includes this feature. Look for a dashboard symbol (usually a windscreen icon with heat waves) when you activate the function, or check your infotainment settings for a heating or climate option linked to the windscreen. Some vehicles have a dedicated button on the stalk or console.

  Replacement impact

  Heated windscreens require replacement glass to be of the correct heated specification — standard unheated glass cannot be fitted. The replacement glass must be sourced to match your vehicle's exact heated-wire configuration. Installation is straightforward, though the technician will confirm the heating element is functioning correctly after fitting. No calibration is required for this feature.

• Right Hand Drive Part20

  2003–2026

  A glass variant made specifically for right-hand-drive vehicles like UK cars, with brackets and sensors positioned for the driver's side.

  What it means

  Right-hand-drive glass is a windscreen (or other glass panel) manufactured to the correct specification for vehicles where the steering wheel and driver controls are on the right side of the car. The key difference isn't the glass itself but the position of brackets, sensor mounting pads, and sometimes a VIN (Vehicle Identification Number) notch. These are placed on the dashboard side to align with right-hand-drive vehicle architecture. Using the correct variant ensures all safety systems, mounting points, and sensor arrays sit in the right place when the glass is fitted.

  How to tell

  Check your vehicle's specification sheet or service handbook — it will confirm 'RHD' (right-hand drive). Ask your dealership or service centre which windscreen variant they stock for your model. If you're unsure, provide us with your registration number when you book; we'll identify the correct part.

  Replacement impact

  UKCG stocks the UK-specific right-hand-drive variant, so all brackets, sensors, and mounting points align correctly during fitting. Using a left-hand-drive part on a right-hand-drive vehicle would result in misalignment of camera brackets, rain sensors, or other dashboard-mounted components. We confirm you receive the correct RHD variant before dispatch.

• Camera16

  2012–2026Calibration varies by vehicle

  A camera mounted near the rear-view mirror monitors the road ahead for lane-keep and traffic-sign features.

  What it means

  A forward-facing camera positioned in the windscreen header area (typically mounted on or near the rear-view mirror bracket) captures video of the road ahead. This camera feeds data to driver-assistance systems such as lane-departure warning, lane-keep assist, autonomous emergency braking, and traffic-sign recognition. The camera is a core component of modern ADAS (Advanced Driver Assistance Systems) and requires precise alignment after windscreen replacement to ensure these safety features function correctly.

  How to tell

  Look for a small dark triangular or lens-shaped component mounted in the black plastic trim area above the windscreen, typically centred near the rear-view mirror or slightly to one side. Your vehicle's handbook or infotainment menu may reference 'Lane Assist', 'Traffic Sign Recognition', or 'Autonomous Emergency Braking'. Ask your dealer or service centre directly if your car is equipped with a forward-facing camera system.

  Replacement impact

  Windscreen replacement on camera-equipped vehicles requires calibration of the camera system after the new glass is fitted. The exact calibration procedure—whether static (using a target board in a controlled environment) or dynamic (road-based)—varies by vehicle make, model, and year. We confirm the precise calibration requirement when we look up your specific vehicle. Calibration ensures lane-keep, sign recognition, and emergency-braking systems function safely. This may extend the fitting schedule and may necessitate workshop-based fitting rather than mobile attendance.

  Calibration mix across our Mitsubishi variants

  • 1Dynamic

  We confirm the exact procedure for your specific vehicle when you book.

• Heated Wiper Rest Area15

  1991–2026

  Heating elements embedded in the glass melt ice from your wipers and the bottom of your windscreen.

  What it means

  A heated wiper rest area uses electric heating elements embedded into the windscreen in the area where your wipers park when not in use. These elements warm the glass to prevent ice and frost from bonding to the wiper blades and the lower windscreen edge during cold weather. This reduces the effort needed to clear ice in the morning and helps protect your wipers from damage caused by frozen adhesion to the glass.

  How to tell

  Check your windscreen's lower edge where the wipers rest — you may see faint heating lines or elements visible in the glass. Your handbook or service history will confirm the feature. You can also ask your dealer or service centre whether your vehicle is equipped with a heated wiper rest area.

  Replacement impact

  When replacing a windscreen with a heated wiper rest area, the replacement glass must include the heating elements. Aftermarket and OE glazing suppliers offer this feature, but availability varies by vehicle. The heating system does not require calibration after replacement, though the technician will ensure the heating element connections are properly restored during installation.

• Bracket For Safety Features13

  2012–2026Calibration varies by vehicle

  The moulded trim that surrounds your camera and sensor cluster at the top of the windscreen, typically transferred or supplied with replacement glass.

  What it means

  A bracket for safety features is the moulded plastic or composite shroud that sits at the top of the windscreen, framing and protecting the camera and sensor cluster mounted behind the rear-view mirror. This trim cover houses forward-facing driver-assistance cameras and sensors — equipment that monitors the road ahead for lane-keeping, collision warning, adaptive cruise control, and similar safety functions. The bracket itself is part of the vehicle's structural frame, but the trim cover you see is what protects and aesthetically integrates the technology into the windscreen area.

  How to tell

  Look at the top centre of your windscreen, just above or around the rear-view mirror. If you see a dark moulded shroud or trim panel — often rectangular or tapered — with a visible lens or sensor window, your vehicle has a bracket for safety features. Your service history or handbook will list any ADAS (Advanced Driver Assistance System) technologies fitted. Ask your dealer or service centre if your vehicle has forward-facing cameras or sensors; if it does, you have a bracket for safety features.

  Replacement impact

  On windscreen replacement, the trim cover is typically transferred from your old glass to the new one, or supplied pre-integrated with the replacement depending on the variant. This means minimal disruption to your safety system during the swap. However, if the bracket requires recalibration after glass replacement — which depends on your specific vehicle and camera type — the job may require static calibration (using a target board) or dynamic calibration (a road drive). We confirm the exact calibration procedure when we look up your vehicle.

  Calibration mix across our Mitsubishi variants

  • 1Dynamic

  We confirm the exact procedure for your specific vehicle when you book.

• Dynamic Camera Calibration Process7

  2012–2026Calibration varies by vehicle

  Dynamic calibration uses road driving to recalibrate your camera after windscreen replacement.

  What it means

  Dynamic camera calibration is a procedure in which a technician drives the vehicle on marked roads at set speeds after the windscreen has been fitted and the adhesive has cured. During this drive, the forward-facing camera relearns its reference points — lane markings, road signs, road edges and surrounding traffic patterns — so it can resume accurate operation of camera-dependent safety and driver-assistance systems. This recalibration is necessary because any windscreen replacement, even with precision fitting, can introduce small shifts in the camera's optical alignment relative to the road.

  How to tell

  Check your vehicle's handbook or contact your dealer to confirm whether your car has a forward-facing camera system. If it does, ask the dealer whether your specific model requires dynamic (road-drive) or static (target-board) calibration after windscreen replacement. You can also ask your fitter — they will establish this when they look up your vehicle's specification.

  Replacement impact

  After your windscreen is fitted and the bonding has cured, a technician will drive the vehicle on marked roads at controlled speeds to allow the camera to relearn its environment. This extends the overall job duration beyond the glass-fitting time alone. Depending on your vehicle, calibration may be performed during the same visit or scheduled separately. We confirm the exact procedure and location (mobile or workshop) when we look up your specific vehicle.

• Encapsulation7

  2006–2026

  Factory-bonded rubber or polymer trim means your replacement glass arrives ready to fit as one complete unit.

  What it means

  Encapsulation is a rubber or polymer gasket moulded directly onto the glass edges during manufacturing. The trim is bonded to the glass at the factory — either by injection moulding, PU robot extrusion, or adhesive bonding. When you need a replacement, the entire panel arrives with its trim already attached, so the glass and gasket are replaced together as a single unit rather than as separate components.

  How to tell

  Check your current windscreen or rear window edges. If you see a continuous rubber or polymer seal running around the perimeter that appears moulded or permanently bonded to the glass itself — rather than a separate trim clipped or screwed to the frame — your glass is encapsulated. Ask your dealer or service centre to confirm; they can also check your vehicle specification sheet.

  Replacement impact

  Encapsulated glass simplifies replacement because there's no separate trim to remove, refit, or source. The bonded gasket is replaced as part of the glass unit, which reduces installation complexity and potential leak points. Cure time and drive-away procedures remain unchanged. No additional sourcing delays — encapsulated replacements are stocked as complete assemblies by most suppliers.

• Bronze5

  1987–2000

  Bronze tint reduces glare and heat whilst maintaining a warm aesthetic that complements most vehicle interiors.

  What it means

  Bronze tint is a coloured coating applied to the windscreen during manufacture to reduce solar heat transmission and glare from sunlight. It's one of several standard tint options (alongside green, grey, and blue) offered by most vehicle makers. The tint doesn't impair visibility but gives the glass a warm, brownish appearance when viewed from outside. Most modern vehicles have some form of windscreen tint as standard—it's rarely a clear, untinted windscreen.

  How to tell

  Roll down a side window halfway and hold a white piece of paper behind the glass from outside. If you see a bronze or warm-brown tint in the side window, your windscreen carries the same tint. Alternatively, ask your vehicle's dealer or service centre for the original windscreen specification—they can confirm the tint colour code. Most documentation refers to it as 'bronze' or occasionally 'warm bronze'.

  Replacement impact

  When replacing a windscreen with bronze tint, the replacement glass must match the original tint specification exactly. Fitting an untinted or differently tinted windscreen will create a noticeable colour mismatch with the side windows and alter the vehicle's interior light and thermal characteristics. We confirm the exact tint code from your vehicle's records and source an OE-equivalent or OEM glass to preserve the original appearance and performance.

• LIDAR4

  2016–2026Bespoke calibration

  LIDAR helps your car sense its surroundings for advanced safety and driver-assistance features.

  What it means

  LIDAR (Light Detection and Ranging) is a sensor technology that uses laser beams to detect objects, obstacles, and road features in three dimensions. It creates a detailed map of the vehicle's surroundings in real time, enabling advanced driver-assistance systems (ADAS) such as adaptive cruise control, collision avoidance, and autonomous emergency braking. LIDAR complements camera and radar systems by providing precise distance and depth information, even in poor visibility or low-light conditions. It is increasingly fitted to modern vehicles as part of their safety and autonomous-capability infrastructure.

  How to tell

  Check your vehicle's handbook or contact your dealership to confirm LIDAR fitment. LIDAR sensors are typically mounted on the roof, bumpers, or within the windscreen/rear-window frame area. You may see reference to 'LIDAR', 'laser radar', or specific safety-feature names (e.g. 'adaptive cruise control', 'autonomous emergency braking') that rely on LIDAR in your documentation.

  Replacement impact

  If your windscreen or rear window houses or frames a LIDAR sensor, replacement requires careful handling to preserve or recalibrate the sensor post-fit. LIDAR calibration procedures vary significantly by vehicle make, model, and year—some require static alignment using specialist target equipment, others demand dynamic road-drive procedures, and some use a combination. We identify the exact calibration requirement when we look up your specific vehicle and confirm it with you before booking.

• Static Camera Calibration Process4

  2016–2026Static calibration required

  Static calibration uses printed targets indoors to align your forward-facing camera after windscreen replacement.

  What it means

  Static camera calibration is a procedure in which a forward-facing camera system is realigned using printed target boards positioned at manufacturer-specified distances and heights in front of the vehicle. The vehicle remains stationary indoors throughout. A diagnostic tool reads the camera's view of these targets and adjusts the camera's alignment to factory specification. This ensures the camera can accurately detect road features, lane markings, pedestrians, and other objects — critical for driver-assistance systems like lane-keeping, collision warning, and adaptive cruise control to function safely and reliably.

  How to tell

  Check your vehicle's handbook or ask your dealer's service centre whether your car has a forward-facing camera system that requires calibration after windscreen replacement. Look for driver-assistance features like lane-keeping assist, autonomous emergency braking, or adaptive cruise control on the dashboard menu. If your vehicle manual mentions 'camera calibration' or 'static target calibration', static calibration is likely part of your windscreen replacement service.

  Replacement impact

  When a windscreen with an integrated or bracket-mounted camera is replaced, the camera's alignment can shift. Static calibration realigns the camera using indoor target boards, which must be performed in a workshop environment where printed targets can be positioned and secured at precise distances. This procedure is conducted after the windscreen is fitted and bonded. The workshop booking accommodates the additional time required for calibration, and we apply the no-split policy — both replacement and calibration happen at the same location on the same visit.

• Green Sun Strip3

  1992–2026

  A green-tinted band at the windscreen's top edge that reduces glare from sunlight above.

  What it means

  A green sun strip is a graduated tint band integrated into the windscreen's laminate at the upper edge. It filters intense sunlight and glare from above — particularly useful on motorways and in bright conditions — whilst maintaining clarity through the main viewing area below. The tint is permanent, fused into the laminate layer during manufacture, and cannot be applied or removed afterwards. Sun strips are a windscreen-only feature because they must be built into the laminate during production; side and rear glass cannot carry them as they are typically toughened rather than laminated.

  How to tell

  Look at the top edge of your windscreen from the inside. A sun strip appears as a distinct green-tinted gradient band that fades from darker at the very top to clear below. It is visible whether the car is parked or moving. You can also check your vehicle's specification sheet or ask your dealership or current service centre to confirm whether your windscreen includes a sun strip.

  Replacement impact

  The replacement windscreen must be the green sun strip variant to match your original. This is not a post-fit addition; it must be ordered as part of the glass itself. Availability is usually straightforward for current and recent models from major manufacturers, though older or less common variants may require a longer lead time. The sun strip does not affect calibration requirements or cure time — it is simply a laminate feature and does not complicate the fitting process.

• Solar Control3

  2006–2026

  Solar control glass absorbs infrared rays to reduce heat and improve cabin comfort.

  What it means

  Solar control is a coating applied to the windscreen that absorbs the sun's infrared radiation rather than allowing it to pass through into the cabin. This reduces solar heat gain, helping to keep the interior cooler and more comfortable, particularly in warm weather or direct sunlight. The coating is transparent to visible light, so it doesn't darken the windscreen or affect visibility. It's a passive thermal management feature that works continuously whenever the sun is shining on the glass.

  How to tell

  Check your vehicle's specification sheet or contact your dealership service centre to confirm whether solar control glass is fitted. Some manufacturers list it as 'solar control windscreen', 'heat-reflective glass', or 'thermal management glass'. It's a factory-fitted feature and won't be visibly obvious from outside the car — the coating is integral to the glass itself.

  Replacement impact

  Solar control glass is a factory-fitted specification. When replacing the windscreen, a solar control variant must be sourced to match the original. This is a standard glass type with no special fitting implications or calibration requirements. Cure and drive-away times follow normal windscreen bonding procedures. Confirm with your fitter that the replacement glass includes solar control to maintain the original thermal performance.

• Clear2

  1986–2026Calibration varies by vehicle

  Clear windscreen glass has no tint; most cars have a slight tint as standard.

  What it means

  A clear windscreen contains no added tint layer. Most modern windscreens incorporate a subtle tint (typically blue, green, grey or bronze) as standard to reduce glare, provide UV protection, and improve cabin comfort. A genuinely clear windscreen is the absence of this tint. Clear glass is less common than tinted variants and is sometimes specified for aesthetic or operational reasons, though the tint difference is usually imperceptible to the naked eye.

  How to tell

  Lower your side window halfway and hold a white piece of paper behind it. If you see a noticeable colour cast (blue, green, grey or bronze) in the side glass, your windscreen has the same tint. If the side glass appears colourless, your windscreen is likely clear. You can also ask your vehicle's dealership or service centre to confirm the windscreen specification in your service records.

  Replacement impact

  Clear windscreen replacement uses the same installation process as any other windscreen. No special calibration or extended cure time applies. Sourcing is straightforward — clear glass is widely available as an aftermarket replacement. Installation time and drive-away restrictions follow standard windscreen replacement timings. If your vehicle has ADAS features (forward-facing camera or radar), calibration may be required after replacement depending on your specific vehicle; we confirm this when we look up your car details.

• Grey2

  1977–2000

  Grey tint reduces glare and heat while maintaining a natural appearance — present on most modern windscreens.

  What it means

  Grey tint is a light, neutral coloured coating applied during manufacture to reduce solar heat and glare transmission through the windscreen. Unlike darker tints (bronze, green, blue), grey tint is barely perceptible to the driver and passenger — most people don't realise it's there. It's one of the most common factory tints on modern vehicles because it balances comfort (heat and glare reduction) with visibility and safety (minimal colour shift to the road ahead). The tint is integral to the glass itself, not a film applied afterwards.

  How to tell

  Roll your side window halfway down and hold a white piece of paper behind it. Look at the glass in natural daylight. If you see a subtle grey tone — cooler-looking than clear glass — your windscreen has grey tint. You can also check your vehicle's specification sheet or ask your dealership service centre. Grey tint is so light that many drivers mistake it for no tint at all.

  Replacement impact

  Grey tint is purely a manufacturing characteristic and does not affect windscreen replacement. The replacement glass is supplied with the same factory tint to match your vehicle's aesthetics and maintain heat rejection performance. No calibration, cure extension, or special handling is required. The tint is fused into the glass during production, not applied afterwards.

• Mono Camera2

  2013–2026Calibration varies by vehicle

  A single camera mounted near the rear-view mirror that helps with lane-keeping and collision avoidance.

  What it means

  A mono camera is a single-lens camera positioned behind the windscreen, typically in the upper centre area near the rear-view mirror. It captures the road ahead and uses computer vision to detect lane markings, vehicles, and road hazards. The camera feeds data to driver-assistance systems such as lane-keeping assist, lane-departure warning, and forward-collision warning. It forms the visual foundation of these safety features, allowing the vehicle to monitor road position and surrounding traffic automatically.

  How to tell

  Look in the black trim area above the windscreen, centred behind the rear-view mirror — you will see a small triangular lens assembly or dark lens cover. Check your vehicle handbook or ask your dealer's service department to confirm your model has lane-assistance or collision-warning features; vehicles with these systems almost always have a mono camera. Dashboard warning symbols related to lane or collision systems also indicate the presence of this camera.

  Replacement impact

  When the windscreen is replaced, the camera bracket and lens assembly must be removed and carefully repositioned on the new glass. The camera may require calibration after fitting to ensure accurate road detection and lane recognition. Calibration needs vary by vehicle — we confirm the exact procedure when we look up your specific vehicle. The job may take longer than a standard windscreen replacement, and workshop facilities may be required if calibration demands a controlled environment.

• Bronze Sun Strip1

  2003–2006

  A bronze-tinted gradient band at the top filters strong overhead glare while maintaining visibility.

  What it means

  A bronze sun strip is a factory-applied tinted gradient band integrated into the windscreen's laminate at the top edge. It progressively darkens from clear to bronze, reducing glare from the sun and bright reflections above the driver's sightline. The strip is built into the laminate layer during manufacture, making it a permanent part of the glass rather than a surface coating. This feature is unique to windscreens — tempered side and rear windows cannot carry laminated components.

  How to tell

  Look at the top edge of your windscreen from the outside. If present, you'll see a graduated bronze or amber tint band that sits above the driver and passenger sightlines and fades downward into the clear glass. It's most obvious when sunlight is strong. Check your vehicle's specification sheet or ask your dealer if you're uncertain — sun strips are listed as a factory option or standard feature depending on model and trim.

  Replacement impact

  A replacement windscreen with an identical sun strip must be sourced to match the original specification. Sun strips are built into the PVB laminate and cannot be added or modified after manufacture. The glass is ordered as a distinct part number from a plain windscreen. Installation and cure follow standard windscreen procedures. No additional calibration is required for the sun strip itself, though any ADAS cameras mounted on the windscreen may require calibration depending on your vehicle.

• Fitting Hardware1

  2015–2026

  Pre-fitted clips and brackets that secure the glass to your vehicle, supplied ready to bond as a complete unit.

  What it means

  Fitting hardware comprises the clips, brackets, mouldings and adhesive retention components that hold the glass securely in place on your vehicle's frame. When your replacement glass is supplied with fitting hardware pre-attached, it arrives as a ready-to-install assembly rather than as bare glass requiring separate hardware attachment during the fit. This streamlines the replacement process and ensures correct positioning and fitment.

  How to tell

  Check your vehicle's service history or contact your dealership service department with your registration number. They can confirm whether your glass comes with pre-fitted hardware as standard. Visually, pre-fitted hardware appears as clips or brackets already bonded or attached to the glass edges before it reaches the fitting technician.

  Replacement impact

  Glass supplied with pre-fitted hardware typically requires no additional labour to attach clips or brackets during the fit, reducing technician time at the vehicle. The hardware must be in good condition and correctly positioned for the glass to seal and function properly. If hardware is damaged during removal of the old glass, replacement or repair of that hardware may be needed before the new glass can be fitted securely.

• Grey Sun Strip1

  1977–1987

  A grey-tinted band across the top of your windscreen that reduces glare from sunlight and reflections above.

  What it means

  A grey sun strip is a tinted gradient band built into the top edge of the windscreen during manufacture. It sits within the laminated glass layers and gradually fades from opaque grey at the very top to clear further down. The strip is designed to reduce glare and reflections from sunlight, street lights, and oncoming headlights, improving comfort and visibility for the driver without obstructing the view of traffic signals or overhead hazards. Sun strips are a factory-applied feature unique to windscreens—they cannot be added to side or rear glass because those are typically toughened rather than laminated.

  How to tell

  Look at the top of your windscreen from inside the vehicle. You will see a grey-tinted band that fades to clear glass. The tint is gradual and integral to the glass itself, not a removable film or coating. Your vehicle's service records or handbook may also list it as a standard feature. If unsure, ask your dealer or service centre whether your specific model includes a sun strip.

  Replacement impact

  When replacing a windscreen with a sun strip, the replacement glass must be sourced in the exact matching variant—including the sun-strip tint and fade profile. Aftermarket and OE glass are both available for most vehicles, but the variant must be correct to match your original. There is no calibration required for the sun strip itself. If your windscreen also carries camera or sensor features, those will be calibrated separately according to your vehicle's needs.

• Silkscreen Modification1

  2003–2008

  A modified black-printed area around the rear-view mirror to suit your vehicle's camera or sensor layout.

  What it means

  Silkscreen modification refers to a variation in the black-printed area (called the 'frit') that surrounds the rear-view mirror on your windscreen. This printed zone is shaped to accommodate your vehicle's specific camera, sensor, or ADAS equipment layout. Different vehicles — even within the same model range — may have different camera positions or sensor configurations, requiring a bespoke print pattern. A silkscreen-modified windscreen is a distinct part with its own part number and cannot be used interchangeably with the standard print variant.

  How to tell

  Check your windscreen documentation or the original part number — dealership service records will confirm whether your windscreen carries a modified silkscreen. You can also ask your dealer's parts department to confirm the exact print variant for your vehicle's year and specification. The modification itself is visible as the black-printed border around the mirror area, but identifying whether it's 'modified' requires checking the part number rather than visual inspection alone.

  Replacement impact

  When your windscreen requires replacement, we must source the correct silkscreen variant for your specific vehicle to ensure proper camera and sensor clearance. Using an incorrect print variant could obstruct camera fields of view or interfere with sensor operation, compromising ADAS functionality and safety. We confirm the exact part number during the booking process to guarantee the correct glass is supplied and fitted. No additional calibration is triggered by the silkscreen modification itself; any calibration needed relates to the camera or sensor system, not the print.
